> >>>WS-C3650-48FD-E Cisco Catalyst Switch
WS-C3650-48FD-E Cisco Catalyst 3560 48FD-E Switch 查看大圖

WS-C3650-48FD-E Cisco Catalyst Switch

13-2-3-4

新商品

  • Total Network Port: 48 x 10/100/1000
  • Total SFP Port: 2 x 10 Gigabit SFP+
  • Network Chipset: Cisco Catalyst 3650 48 Port Full PoE 2x10G Uplink IPServices
  • Manageable: Yes
  • Network Layer: 3
  • Power Over Ethernet: 775W
  • Stackable: Stackable

更多資訊

by order

加購項目

必選。請詳細閱讀各項敘述。

  • 設備維護合約 / 年: NT$15000

    包含
    1. IP 路由規劃顧問
    2.一年遠端技術支援
    NT$ 15,000
    設備維護合約 / 年: NT$15000

    NT$ 15,000

  • 安裝設定(含顧問諮詢) / 時: NT$8000

    服務包含
    1. 第一次到府安裝設定
    2. 顧問諮詢 /時

    下單時加購此服務可立即現金折抵5000元。
    PS: 訂單成立時未加購此服務，等於當筆訂單放棄此優惠。
    售後若需要安裝設定服務，需付原價8000元。
    NT$ 8,000
    安裝設定(含顧問諮詢) / 時: NT$8000

    NT$ 8,000

  • 本次採購不需安裝設定服務

    本次採購不需安裝設定服務

NT$ 378,000 未稅

新增至待購列表

商品規格

品牌 Cisco
連接埠數量 48 port
管理階級 layer 3
傳輸速率 Gigabit
PoE供電 有PoE
光籤模組 (SFP) 2 PORT SFP+

商品介紹

Cisco Catalyst 3560 48FD-E Switch 介紹

  • 48 * 10/100/1000 Ethernet ports and 2 * 1G SFP & 2 * 10G SFP+ or 4 * 1G SFP uplink ports
  • 775W POE power budget with up to 30W per port
  • IP service feature set IOS image with Flexible Netflow and wireless controller functionality
  • Advanced layer 3 routing features: OSPF, EIGRP, BGP, IS-IS, VRP-lite, PIM-DM, PIM-SM, PIM sparse-dense mode, SSM, IPv6 routing
  • Up to 9 members stacking and up to 160Gbps of stack throughput
  • Up to 40G wireless bandwidth per switch, up to 25 APs and 1000 Wireless clients for each switching entity
  • Support Cisco Aironet 1040/1140/1260/1600/2600/3500/3600/3700 series APs
  • Power redundant and fans redundant modular option
  • 4GB memory (DRAM) and 2GB flash

Cisco Catalyst WS-C3650-48FD-E is the next generation of enterprise-level standalone switch with stacking option for access-layer and distribution-layer design. WS-C3650-48FD-E integrates 48 Gigabit Ethernet POE+ ports and 2 * 1G SFP & 2 * 10G SFP+ (SFP+ is compatible with SFP) uplink ports in IP service feature set which enables advanced layer 3 routing performance with superior QoS capabilities. Cisco Catalyst 3650 series switches process both wired and wireless services on a single platform. Cisco StackWise-160 creates high scalability and resilient unified system with up to stack 9 switches to simplify the network management, and it also enables stateful switchover on stacking to provide redundancy. IP service feature set enables wireless controller functionality with supporting up to 25 wireless APs and 1000 wireless connections (AP licenses purchase separately). For stacking purpose, stack modules are required; in addition, IP service feature set can only stack with other 3650 series in IP service feature set, in order to stack with LAN/IP base feature set, IP service feature set need to configure in LAN/IP base feature set (Stack module purchase separately). Flexible Netflow monitors the network traffic flows to identify the threat of network.


Cisco Catalyst 3560 48FD-E Switch 規格

                     Cisco Catalyst 3650-48FD-E Specifications
Model info: WS-C3650-48FD-E
Enclosure type Rack-mountable - 1U
Ports 48 x 10/100/1000 (POE+)  + 2 x 10G SFP+ & 2 x 1G SFP
Network management Interface ● Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling
● Management console port: RJ-45-to-DB9 cable for PC connections
Available PoE Power 775W
Switching Capacity 176Gbps
Maximum stacking number 9
Stack Bandwidth 160Gbps
Forwarding Performance 104.16Mpps
FNF entries 48000
Maximum VLANs IDs 4,094
MAC Address Table Size 32K
CPU Multicore CPU
RAM 4 G
Flash Memory 2 G
Wireless
Number of AP per switch/stack 25
Number of wireless clients per switch/stack 1000
Total number of WLANs per switch 64
Wireless bandwidth per switch up to 40Gbps
Supported Aironet AP series 3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
Expansion / Connectivity
Console ports USB (Type-B), Ethernet (RJ-45)
Expansion Slot(s)  power redundant slot
Accessory & Rack Moubt Kits ●ACC-KIT-T1: Accessory kit
●RACK-KIT-T1: Rack mount kit
●4PT-KIT-T1:Extension rails and brackets for four-point mounting
Stacking module & cable ●C3650-STACK-KIT: Stack Module
●STACK-T2-50CM: StackWise-160 stacking cable with a 0.5 m length
●STACK-T2-1M: StackWise-160 stacking cable with a 1.0 m length
●STACK-T2-3M: StackWise-160 stacking cable with a 3.0 m length
Power supply PWR-C2-1025WAC
Power Device Power supply - redundant - plug-in module
Power Redundancy optional
Voltage range (Auto) 100V-240V
Power Consumption of standalone (in Watts) 109.4 (max)
Miscellaneous
Width 17.5 Inches (44.5 Cm)
Depth 19.125 Inches (48.6 Cm)
Height 1.73 Inches (4.4 Cm)
Weight 17.2 Pounds (7.80Kg)
Rack Mounting Kit optional
 MTBF in hours 383,760
Compliant Standards ● IEEE 802.1D Spanning Tree Protoco
● IEEE 802.1p CoS Prioritization
● IEEE 802.1Q VLAN
● IEEE 802.1s
● IEEE 802.1w
● IEEE 802.1X
● IEEE 802.1X-Rev
●IEEE 802.11
● IEEE 802.1ab (LLDP)
● IEEE 802.3ad
● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports		 ● IEEE 802.3 10BASE-T
● IEEE 802.3u 100BASE-TX
● IEEE 802.3ab 1000BASE-T
● IEEE 802.3z 1000BASE-X
● RMON I and II standards
● SNMP v1, v2c, and v3
System software / license
System software IOS IP Service
EnergyWise license ENERGY-MGMT, ENERGY-MGT-100-K9
Access Point Licenses ●L-LIC-CT3650-UPG: Primary upgrade license SKU for Cisco 3650 wireless controller (e-delivery)
●L-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based wireless controller (e-delivery)
●L-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based wireless controller (e-delivery)
●LIC-CTIOS-1A: 1 access point adder license for the Cisco IOS Software based wireless controller (paper license)
features ●EEM ● RPS Support  ● IP service-level agreements (SLAs)  ● Advanced IP unicast routing protocols ● Jumbo Frames ● VLANS●Voice Vlan ●VTPv2 ●CDPv2 ●LLDP ● 802.3ad LACP and PAgP ● PVST/PVST+ ●802.1W/802.1S ●Port Fast/Uplink Fast ●Dynamic Trunking Protocol (DTP) ● port CoS Trust and Override ● Trusted Boundary ● ACL Classification ●ingress Policing ● Auto QoS ●Per VLAN policies ● 802.1p queues ●Scheduling ● Priority Queuing ● Configure CoS Priority Queues ●Configure CoS Priority Queues ● Configure Queue Weights ●Configure Buffers and Thresholds ●Class & Policy Maps ● Modify CoS and DSCP Mapping● Weighted Tail Drop ● IGMPv1,v2,v3 and MLDv1, v2 ● DHCP server ● DSCP transparency ● HSRP, VRRP, BLGP ● RIPv1, v2 EIGRP, PIM  OSPF, OSPFv3, EIGRPv6, BGPv4, IS-ISv4  ● VRF-lite  ● PIM-SM/DM, PIM sparse-dense mode, SSM ● Flexible Netflow
Advanced Network security ● Port security ● DHCP snooping ●Dynamic ARP inspection (DAI) ● IP source guard ●The Unicast Reverse Path Forwarding (uRPF)
● Bidirectional data support on a SPAN ● User authentication
● Private VLAN  ●Router and VLAN ACLs  ●complete identity and security
● Multidomain authentication ● MAC address notification
● IGMP filtering ● Cisco security VLAN ACL
● Secure Shell (SSH) Protocol, Kerberos, and Simple Network Management Protocol Version 3 (SNMPv3)
● Port-based ACLs ● TrustSec SXP ● IEEE 802.1ae
● TACACS+ and RADIUS authentication ●Cisco standard and extended IP security router ACLs
●  Bridge protocol data unit (BPDU) Guard
● Spanning Tree Root Guard (STRG) ● Wireless end-to-end security
Management ●BRIDGE-MIB ●CISCO-AUTH-FRAMEWORK-MIB
●CISCO-BGP4-MIB, BGP4-MIB ●CISCO-BRIDGE-EXT-MIB
●CISCO-BULK-FILE-MIB ●CISCO-CABLE-DIAG-MIB
●CISCO-CALLHOME-MIB ●CISCO-CEF-MIB
●CISCO-CIRCUIT-INTERFACE-MIB
●CISCO-ENTITY-VENDORTYPE-OID-MIB
●CISCO-CONTEXT-MAPPING-MIB
●CISCO-DEVICE-LOCATION-MIB ●CISCO-DHCP-SNOOPING-MIB
●CISCO-EIGRP-MIB
●CISCO-EMBEDDED-EVENT-MGR-MIB
●CISCO-ENTITY-FRU-CONTROL-MIB ●CISCO-ENTITY-SENSOR-MIB
●ENTITY-MIB ●CISCO-ERR-DISABLE-MIB
●CISCO-CONFIG-COPY-MIB ●CISCO-FLOW-MONITOR-MIB
●CISCO-FTP-CLIENT-MIB ●CISCO-HSRP-EXT-MIB
●CISCO-HSRP-MIB ●CISCO-IETF-ISIS-MIB
●CISCO-IF-EXTENSION-MIB ●CISCO-IGMP-FILTER-MIB
●CISCO-CONFIG-MAN-MIB ●CISCO-IP-CBR-METRICS-MIB
●CISCO-IPMROUTE-MIB ●CISCO-IP-STAT-MIB
●CISCO-IP-URPF-MIB ●CISCO-L2L3-INTERFACE-CONFIG-MIB
●CISCO-LAG-MIB ●CISCO-LICENSE-MGMT-MIB
●CISCO-MAC-AUTH-BYPASS-MIB ●CISCO-MAC-NOTIFICATION-MIB
●CISCO-MDI-METRICS-MIB ●CISCO-FLASH-MIB ●CISCO-OSPF-MIB
●CISCO-OSPF-TRAP-MIB ●CISCO-PAE-MIB●CISCO-PAGP-MIB
●CISCO-PIM-MIB ●CISCO-PING-MIB ●CISCO-PORT-QOS-MIB
●CISCO-PORT-SECURITY-MIB●CISCO-PORT-STORM-CONTROL-MIB
●CISCO-POWER-ETHERNET-EXT-MIB●CISCO-PRIVATE-VLAN-MIB
●CISCO-PROCESS-MIB ●CISCO-PRODUCTS-MIB●CISCO-RF-MIB
●CISCO-RTP-METRICS-MIB ●CISCO-RTTMON-MIB
●CISCO-SMART-INSTALL-MIB		 ●CISCO-SNMP-TARGET-EXT-MIB ●CISCO-STACKMAKER-MIB
●CISCO-MEMORY-POOL-MIB ●CISCO-STP-EXTENSIONS-MIB
●CISCO-SYSLOG-MIB ●CISCO-TCP-MIB●CISCO-UDLDP-MIB
●CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB ●CISCO-VLAN-MEMBERSHIP-MIB●CISCO-VTP-MIB ●EtherLike-MIB
●HC-RMON-MIB ●IEEE8021-PAE-MIB●IEEE8023-LAG-MIB
●IF-MIB ●IGMP-MIB ●IGMP-STD-MIB ●IP-FORWARD-MIB
●IP-MIB ●IPMROUTE-STD-MIB ●LLDP-EXT-MED-MIB
●LLDP-MIB ●NOTIFICATION-LOG-MIB
●OLD-CISCO-MEMORY-MIB ●CISCO-CDP-MIB
●POWER-ETHERNET-MIB ●RMON2-MIB
●RMON-MIB ●SNMP-COMMUNITY-MIB●SNMP-FRAMEWORK-MIB
●SNMP-MPD-MIB ●SNMP-NOTIFICATION-MIB ●SNMP-PROXY-MIB
●SNMP-TARGET-MIB ●SNMP-USM-MIB●SNMPv2-MIB
●SNMP-VIEW-BASED-ACM-MIB ●TCP-MIB●UDP-MIB
●CISCO-IMAGE-MIB ●CISCO-STACKWISE-MIB
●AIRESPMACE-WIRELESS-MIB ●CISCO-LWAPP-IDS-MIB
●CISCO-LWAPP-AP-MIB ●CISCO-LWAPP-CCX-RM-MIB
●CISCO-LWAPP-CLIENT-ROAMING-MIB
●CISCO-LWAPP-DOT11-CCX-CLIENT-DIAG-MIB
●CISCO-LWAPP-DOT11-CCX-CLIENT-MIB
●CISCO-LWAPP-DOT11-CLIENT-CCX-REPORTS-MIB
●CISCO-LWAPP-DOT11-CLIENT-MIB●CISCO-LWAPP-DOT11-MIB
●CISCO-LWAPP-DOWNLOAD-MIB●CISCO-LWAPP-LINKTEST-MIB
●CISCO-LWAPP-MFP-MIB ●CISCO-LWAPP-MOBILITY-EXT-MIB
●CISCO-LWAPP-QOS-MIB ●CISCO-LWAPP-REAP-MIB
●CISCO-LWAPP-ROGUE-MIB ●CISCO-LWAPP-RRM-MIB
●CISCO-LWAPP-SI-MIB ●CISCO-LWAPP-TSM-MIB
●CISCO-LWAPP-WLAN-MIB ●CISCO-LWAPP-WLAN-SECURITY-MIB
Technical Support and Services ● Cisco SMARTnet Service ● Cisco Smart Foundation Service ● Cisco SP Base Service ●Cisco Focused Technical Support Services
Environmental Ranges
  Fahrenheit Centigrade
With AC power supply
Operating environment and altitude
Operating temperature up to 5000 ft (1500 m) 23ºF to 113ºF  -5ºC to +45ºC
Operating temperature up to 10,000 ft (3000 m) 23ºF to 104ºF  -5ºC to +40ºC
Short-term exception at sealevel with single fan failure 23ºF to 113ºF -5ºC to +45ºC
Short-term exception up to 5000 feet (1500 m) 23ºF to 122ºF -5ºC to 50ºC
Short-term exception up to 10,000 feet (3000 m) 23ºF to 113ºF -5ºC to 45ºC
With DC power supply
Operating environment and altitude (NEBS)
Operating temperature up to 6000 ft (1800 m) 23ºF to 113ºF  -5ºC to +45ºC
Operating temperature up to 10,000 ft (3000 m) 23ºF to 104ºF  -5ºC to +40ºC
Operating temperature up to 13,000 ft (4000m) 23ºF to 95ºF  -5ºC to 35ºC
Short-term exception up to 6,000 feet (1800 m) 23ºF to 131ºF  -5ºC to +55ºC
Short-term exception up to 10,000 feet (3000 m) 23ºF to 122ºF  -5ºC to +50ºC
Short-term exception up to 13,000 feet (4000 m) 23ºF to 113ºF  -5ºC to +45ºC
Short-term exception at sealevel with single fan failure 23ºF to 113ºF  -5ºC to +45º
Storage environment  -40ºF to 160ºF  -40ºC to 70ºC
  Feet Meters
Operating altitude Up to 16,400 Up to 5000m
Storage altitude Up to 16,400 Up to 5000m
Operating relative humidity 5% to 96% noncondensing
Storage relative humidity 5% to 96% noncondensing
Short-term exception at sealevel with single fan failure 23ºF to 113ºF  -5ºC to +45º
Storage environment  -40ºF to 160ºF  -40ºC to 70ºC
  Feet Meters
Operating altitude Up to 13,000 Up to 4000m
Storage altitude Up to 15,000 Up to 4573m
Operating relative humidity 10% to 95% noncondensing
Storage relative humidity 10% to 95% noncondensing
